Natural White and Warm White

T10 LED Lamp

This might be a press-fit lampshade for affordable 12V 9-LED T10 automotive lamps. I think they're occasionally called "wedge lights, " as they are made use of as turn indicators or interior lights. (I got mine on ebay for $1.50 for 2, shipping included.)

They truly are created for 12V DC operation, which is convenient for reprappers, in addition they do not really need to be fastened towards framework if you're utilizing solid core cable.

These things can be brilliant, as well as the shade does a fantastic job of keeping the light in one single location rather than inside eyes. They might need about 225mm of 3mm filament each (about a nickel).

v1.0 - the first images color down, without any integrated support construction
v1.1 - Prints base down with additional help on shade-to-base transition. (On remaining in picture imprinted in white.)
v1.2 - Prints tone down with simple integrated assistance construction. (On right in picture printed in white.)

1) Print the part. (always check description above which is why version to printing.)
2) remove about 4mm regarding the finishes of a wire (I use twisted pair from old community cable), and place the bare line to the holes privately.
3) Noting which side is good, hit the bulb to the slot and make certain the cables tend to be pushed toward the back and they are maybe not shorted.
4) connect it into to a 12V and aim it someplace interesting.

We created this with OpenSCAD and printed it with yellow 3mm PLA withh a 5mm nozzle on a self-sourced Prusa Mendel. I had to clean up the inside slightly, but besides that it seems to your workplace alright. Love!

Source: www.thingiverse.com
